Zyxel P-2612HW-F1 Modem Router

N300 WiFi Gigabit Dual WAN Router
Zyxel P-2612HW-F1

• Model: P-2612HW-F1
• Typ Portów: RJ-45
• Port WAN: 1 x 10/100
• Port LAN: 4 x 10/100
• Modem ADSL: Tak - ADSL2+
• Chłodzenie: Pasywne
• Urządzenie zarządzalne: Tak
• PoE: Nie
• VoIP: Tak
• Zasilacz: Zewnętrzny
• Standard sieci WiFi: 802.11 B/G
• Prędkość WiFi: 54 Mbps
• Pasmo Częstotliwości: 2,4 GHz
• Przycisk WPS: Tak
• Wbudowana Antena: Nie - 1 antena zewnętrzna, nieodkręcana
• Wymiary: 21,8 × 14,4 × 4 cm
• Waga: 0,500 kg urządzenie, 0,900 kg komplet
• Stan: używany

Adres IP: 192.168.1.1

Login: admin

Hasło: 1234

W zestawie:

• Zasilacz

SPECYFIKACJA:

• DSL Features
  • ADSL compliance/ ITU-T G.992.1/ ITU-T G.992.2 Annex A, B (G.lite)/ ITU-T G.994.1 (G.hs)
  • ADSL2 Compliance/ ITU-T G.992.3 (G.dmt.bis)/ ITU-T G.992.4 (G.lite.bis)
  • ADSL2+ Compliance/ ITU-T G.992.5


• Router Features
  • NAT (includes multi-to-multi NAT) / SUA, 4096 NAT Sessions
  • Full cone NAT
  • NAT Server (Port forwarding)
  • NAT ALGs
  • PPTP/L2TP/IPSec VPN Pass Through
  • PPPoE
  • DHCP Client/Server/Relay
  • DHCP Options (Option 42, 43, 60, 61 and 125)*
  • DNS Proxy
  • Dynamic DNS Support
  • IGMP Snooping and Proxy
  • IGMP Fast Leave
  • IP Multicasting, IGMP v1, v2, v3*
  • IP Alias
  • RIP I/ RIP II Supported
  • Support 16 IP Static Route
  • IP Policy Routing
  • UPnP support
  • Adjustable MTU size (Max 1518 byte)


• Voice Functionality
  • SIP version 2 (RFC 3261)
  • Codec: G.711, G.729a/b
  • Wideband Voice (G.722)*
  • Echo Cancellation: G.168, VAD, Silence Suppression, CNG, Dynamic Jitter Buffer
  • DTMF Detection and Generation
  • DTMF: In-Band and Out-of-Band (RFC 2833), (SIP INFO)
  • Modem and Fax Tone Detection and Pass-through
  • T.38 FAX Relay
  • DNS SRV


• Phone Features
  • Message Waiting Indicator (RFC 3842)
  • Flexible Dial Plan (RFC3525 section 7.1.14)
  • Caller ID
  • FAX Relay: Transparent Fax Relay over G.711
  • Interactive Voice Response (IVR)
  • Call Waiting
  • Call Hold
  • Early Media
  • Flash Hook Timer
  • Call Transferring (Blind and Attended Transfer)
  • Call Forwarding
  • Three Way Conference
  • Abbreviated Dialing (Speed Dialing)
  • Shuttle Enquiry Call (Second Call)
  • Do NOT Disturb (DND)
  • Call Block
  • Calling LINE Identification Presentation (CLIP)
  • Calling LINE Identification Restriction (CLIR)
  • Connected Line Identification Presentation (COLP)
  • Connected Line Identification Restriction (COLR)
  • Conference Call w/ Media Server
  • Caller ID Generation/ Detection w/ DTMF & FSK Format
  • Internal Call
  • Speed Dial (Phone Book)


• VLAN/QoS
  • Support 802.1Q Port/ Tag based VLAN
  • Support 802.1P Priority Bit
  • TOS/ DiffServ
  • Support Flexible Traffic Classification
  • Support 4 Priority Queue
  • Freely Assign the Classified Traffic to Queues, VLAN, or PVC
  • Per VLAN IPR (IP Routing), (Max 4)
  • Per VLAN PPPoE (Max 4)
  • Media Bandwidth Management (MBM) for Triple Play


• Wireless LAN
  • IEEE 802.11g Compliance
  • Button/ PIN Mode Wi-Fi Protected Setup (WPS)
  • Wi-Fi Protected Access support (WPA, WPA PSK, WPA2 (IEEE 802.11i), WPA2-PSK, WPA EAP)
  • 802.11e (WMM)
  • WLAN Bridge to LAN
  • MAC Address Filter
  • Support IEEE 802.1x Multiple SSID (up to 4) Random WPA Key Time Scheduling for Wireless On/Off SSID VLAN-tagging (Guest access)*


• Firewall Security
  • Firewall with SPI
  • Protection of DoS Attacking
  • Content Filtering: URL Keyword Blocking
  • IP & Generic Packet Filtering
  • Real-time Attack Alert and Logs
  • SIP ALG


• Virtual Private Network
  • 2 Concurrent VPN Tunnels
  • IKE and Manual Key Management
  • AH and ESP Protocol
  • DES/ 3DES and AES Encryption
  • SHA-1 and MD5 Authentication
  • Tunnel and Transport Mode Encapsulation
  • IPSec NAT Traversal
  • NETBIOS Pass-through for IPSec


• Network Management
  • Web GUI
  • Command Line Interpreter (CLI)
  • Remote Management for Telnet/FTP/ Web/ SNMP/ ICMP/ DNS.
  • Remote Firmware Upgrade via Web/FTP/TFTP
  • SNMP v1 & v2c with MIB II
  • TR-069/ TR-098/ TR-104
  • TR-064
  • TR111


• Hardware Specifications
  • RJ-11 DSL port for ADSL Annex A and RJ-45 DSL port for ADSL Annex B and U-R2.
  • 4-port Auto MDI/MDI-X 10/100M Ethernet LAN Ports.
  • 1-port auto MDI/MDI-X 10/100M Ethernet WAN port
  • Wi-Fi IEEE 802.11b/g
  • One External Dipole Antenna, Non-detachable.
  • Restore Factory Defaults Button
  • 2 FXS POTS interface
  • A Hardware Switch for DSL/ Ethernet WAN
  • WLAN Button on Top Side for WLAN On/Off and WPS
  • Restore Factory Reset Button
  • Power Consumption: 18W


• Physical Specifications
  • Item weight: 460 g (1.02 lb)
  • Item dimensions (WxDxH): 218 × 144 × 40 mm (8.58" x 5.67" x 1.57")
  • Packing weight: 665 g (1.47 lb)
  • Packing dimensions (WxDxH): 277 × 263 × 77 mm (10.35" x 10.9" x 3.03")


• Environmental Specifications Operating Environment
  • Temperature: 0℃ to 40℃ (32°F to 104°F)
  • Humidity: 20% to 85% RH


• Storage Environment
  • Temperature: -20℃ to 60℃ (-4°F to 140°F)
  • Humidity: 20% to 90% RH


• Certification
  • CE

Sprzęt jest używany, sprawny w 100%.

Brak oryginalnego opakowania.
